Chapter 2: Series 700 Configuration System

3
5

Figure 1 Series 700 Core unit and configurable options

1 700 Series Printer ("Core Unit" Main Chassis Assembly)
2 Bezel Assembly Option
3 Ticket Supply Box (specifiy size)
4 Ticket Present Sensor Option
5 Drawer Chassis Assembly
