Model 750

Standard Features

•
Easy Ticket Loading
•
Self Diagnostics
•
Ticket Out Sensing
•
Black Dot Sensing
•
High Quality Printing (Text, Barcodes, Graphics, Lines)
•
Bitmap Graphics, Portrait, and Landscape Printing
•
Ticket Containment
•
Flexible Configuration Options
•
Optional Ticket Supply Box (Holds up to 400 tickets) (w/ ticket low)

750 Printing Highlights

•
Print Speed:
•
5 Selectable Fonts:
•
Print Modes:
•
Print Resolution:
•
Print Zone Width:
•
Printhead Life:
•
Data Buffer:
•
Memory:
•
Bar Code:

Print Characteristics

The statistics for the five internal fonts the Series 700 Printer supports
appear below. Height and width are expressed in terms of dots.
Height
16
24
32
32
56

Table 1 Font Statistics

Page 6
51 mm/sec (2 in. per second)
7.5 cpi, 10 cpi, 12 cpi, 16.5 cpi, 20 cpi
Normal, Double-High, Double-Wide,
Double-High/Double Wide
8 dots per mm (203 dpi) Horizontal & Verticle
56 mm (2.205 in.)
25 Km
4K
64K EPROM & 32K RAM
3 0f 9, Interleaved 2 of 5, UPC-A & UPC-E. Codabar, EAN8
& EAN13, Code 128, Postnet, and MSI Plessey
Width
10
12
16
20
28
Rev H
Series 700 Maintenance Manual
Horizontal cpi Vertical cpi
20.3 12.7
16.9 8.4
12.7 6.4
10.2 6.4
7.3 3.6
