7.6 Power MOSFET Drain-Source Voltage

Figure 7-9
and
Figure 7-10
The voltage is measured with 1-GHz bandwidth and at the solder mask openings near the U1_P1 IC using a
1-GHz differential probe.
20
TPS546B24A 2-Phase SWIFT™ Step-Down Converter Evaluation Module
User's Guide
show the low-side and high-side MOSFET drain-source voltage (V

Figure 7-9. Low-Side MOSFET V

Figure 7-10. High-Side MOSFET V

Copyright © 2022 Texas Instruments Incorporated
DS
DS
DS
SLUUC48A – FEBRUARY 2020 – REVISED FEBRUARY 2022
Submit Document Feedback
www.ti.com
) at 40-A load.
