Bill of Materials
(1)
Designator Quantity
C16_P1, C16_P2 0
C17_P2 0
C18_P1, C18_P2 0
C26, C27, C28, C37, C38, C39, C40, 0
C41, C42, C43, C44, C45, C46, C56,
C57, C58, C59, C60, C61, C65, C66,
C67, C69, C70, C71, C72
FID1, FID2, FID3, FID4, FID5, FID6 0
J1, J3 0
JP6, JP8 0
R1_P1, R1_P2, R18_P1, R24_P1, 0
R24_P2, R37, R39
R8_P1 0
R10_P1, R10_P2, R11_P1, R11_P2, 0
R12_P1, R12_P2, R20_P1, R20_P2
R13_P1, R13_P2 0
R19_P2 0
R21_P2 0
TP33 0
TP34_P1, TP34_P2, TP35_P1, TP35_P2 0
(1) Unless otherwise noted, all parts can be substituted with equivalents.
30 TPS546B24A 2-Phase SWIFT™ Step-Down Converter Evaluation Module User's Guide
Table 9-1. TPS546B24AEVM-2PH Bill of Materials (continued)
Value Description
0.1 μF CAP, CERM, 0.1 μF, 50 V, ±10%, X7R, 0603
100 pF CAP, CERM, 100 pF, 50 V, ±5%, C0G/NP0, 0603
2.2 μF CAP, CERM, 2.2 μF, 16 V, ±10%, X7R, 0603
47 μF CAP, CERM, 47 μF, 10 V, ±10%, X7R, 1210
Fiducial mark. There is nothing to buy or mount.
Receptacle, 2.54 mm, 6 × 2, Gold, TH
Header, 100 mil, 2 × 1, Tin, TH
0 RES, 0, 5%, 0.1 W, AEC-Q200 Grade 0, 0603
10.0 k RES, 10.0 k, 1%, 0.1 W, 0603
10.5 k RES, 10.5 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603
53.6 k RES, 53.6 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603
14.7 k RES, 14.7 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603
12.1 k RES, 12.1 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603
Test Point, Multipurpose, Red, TH
Test Point, Miniature, Red, TH
Copyright © 2022 Texas Instruments Incorporated
PackageReference PartNumber
0603 C0603C104K5RACTU
0603 GRM1885C1H101JA01D
0603 EMK107BB7225KA-T
1210 GRM32ER71A476KE15L
N/A N/A
Receptacle, 2.54 mm, 6 × SSQ-106-03-G-D
2, TH
Header, 2 × 1, 100 mil, TH 5-146278-2
0603 ERJ-3GEY0R00V
0603 RC0603FR-0710KL
0603 CRCW060310K5FKEA
0603 CRCW060353K6FKEA
0603 ERJ-3EKF1472V
0603 CRCW060312K1FKEA
Red Multipurpose Testpoint 5010
Red Miniature Testpoint 5000
SLUUC48A – FEBRUARY 2020 – REVISED FEBRUARY 2022
www.ti.com
Manufacturer
Kemet
MuRata
Taiyo Yuden
MuRata
N/A
Samtec
TE Connectivity
Panasonic
Yageo
Vishay-Dale
Vishay-Dale
Panasonic
Vishay-Dale
Keystone
Keystone
