Bill of Materials

9 Bill of Materials
Table 9-1 lists the BOM for the TPS546B24AEVM-2PH.
(1)
Designator Quantity
!PCB1 1
C1_P1, C1_P2, C11_P1, C11_P2 4
C2_P1, C2_P2, C33, C34 4
C3_P1, C3_P2, C4_P1, C4_P2, C5_P1, 8
C5_P2, C6_P1, C6_P2
C7_P1, C7_P2, C8_P1, C8_P2, C9_P1, 6
C9_P2
C12_P1, C12_P2 2
C13_P1, C13_P2, C20_P1, C20_P2 4
C15_P1, C15_P2 2
C17_P1 1
C19_P1, C19_P2 2
C21_P1, C21_P2 2
C22 1
C23 1
C24 1
C25, C29, C30, C31, C32, C35, C36, 16
C49, C50, C51, C52, C53, C54, C55,
C62, C68
C47, C48, C63, C64 4
D1, D2 2
D1_P1, D1_P2 2
H1, H2 2
H3, H4, H5, H6 4
H7, H8 2
H9, H10 2
J2 1
J4 1
JP1_P1, JP1_P2 2
JP2_P1, JP2_P2 2
JP3, JP4, JP5 3
JP7_P1, JP7_P2 2
28 TPS546B24A 2-Phase SWIFT™ Step-Down Converter Evaluation Module User's Guide
Table 9-1. TPS546B24AEVM-2PH Bill of Materials
Value Description
Printed Circuit Board
1 μF CAP, CERM, 1 uF, 25 V, ±10%, X7R, 0603
100 μF CAP, AL, 100 μF, 35 V, ±20%, 0.15 Ω, SMD
22 μF CAP, CERM, 22 μF, 25 V, ±10%, X6S, 1210
6800 pF CAP, CERM, 6800 pF, 50 V, ±10%, X7R, 0402
1000 pF CAP, CERM, 1000 pF, 100 V, ±5%, X7R, 0603
0.1 μF CAP, CERM, 0.1 μF, 50 V, ±10%, X7R, 0603
4.7 μF CAP, CERM, 4.7 μF, 10 V, ±10%, X5R, 0603
100 pF CAP, CERM, 100 pF, 50 V, ±5%, C0G/NP0, 0603
2.2 μF CAP, CERM, 2.2 uF, 16 V, ±10%, X7R, 0603
33 pF CAP, CERM, 33 pF, 50 V, ±5%, C0G/NP0, 0603
1 μF CAP, CERM, 1 μF, 50 V, ±10%, X7R, 0805
10 μF CAP, CERM, 10 μF, 10 V, ±20%, X7R, 0805
0.01 μF CAP, CERM, 0.01 µF, 100 V, ±10%, X7R, AEC-Q200
Grade 1, 0603
47 μF CAP, CERM, 47 μF, 10 V, ±10%, X7R, 1210
220 μF CAP, TA, 220 μF, 6.3 V, ±20%, 0.009 Ω, SMD
30 V Diode, Schottky, 30 V, 2 A, AEC-Q101, SOD-123FL
45 V Diode, Schottky, 45 V, 0.75 A, SOD-523
Machine Screw Pan Philips 10-32
Bumpon, Hemisphere, 0.44 × 0.20, Clear
Machine Screw Nut, Hex, 3/8', Stn, Steel, 10-32
Washer, Split Lock, #10
Header (shrouded), 100mil, 5 × 2, Gold, TH
Connector, Receptacle, Micro-USB Type B, R/A, Bottom
Mount SMT
Header, 2.54 mm, 2 × 1, Gold, TH
Header, 100 mil, 3 × 2, Gold, TH
Header, 100mil, 2 × 1, Tin, TH
Header, 100 mil, 3 × 1, Gold, TH
Copyright © 2022 Texas Instruments Incorporated
PackageReference PartNumber
BSR104
0603 C0603C105K3RACTU
SMT Radial G EEE-FC1V101P
1210 GRM32EC81E226KE15L
0402 GRM155R71H682KA88D
0603 06031C102JAT2A
0603 C0603C104K5RACTU
0603 C0603C475K8PACTU
0603 GRM1885C1H101JA01D
0603 EMK107BB7225KA-T
0603 C0603C330J5GACTU
0805 C0805C105K5RACTU
0805 C2012X7R1A106M125AC
0603 GCM188R72A103KA37J
1210 GRM32ER71A476KE15L
7343-31 T520D227M006ATE009
SOD-123FL MBR230LSFT1G
SOD-523 BAS 52-02V H6327
PMSSS 102 0050 PH
Transparent Bumpon SJ-5303 (CLEAR)
HNSS 102
1477
5 × 2 Shrouded header 5103308-1
MICRO USB CONN, R/A 1981568-1
Header, 2.54 mm, 2 × 1, 61300211121
TH
Sullins 100 mil, 2 × 3, 230 PBC03DAAN
mil above insulator
Header, 2 × 1, 100 mil, TH 5-146278-2
PBC03SAAN PBC03SAAN
SLUUC48A – FEBRUARY 2020 – REVISED FEBRUARY 2022
www.ti.com
Manufacturer
Any
Kemet
Panasonic
MuRata
MuRata
AVX
Kemet
Kemet
MuRata
Taiyo Yuden
Kemet
Kemet
TDK
MuRata
MuRata
Kemet
ON Semiconductor
Infineon Technologies
B&F Fastener Supply
3M
B&F Fastener Supply
Keystone
TE Connectivity
TE Connectivity
Wurth Elektronik
Sullins Connector Solutions
TE Connectivity
Sullins Connector Solutions
