Table 4-5. Connector Functions - Texas Instruments TPS546B24AEVM-2PH User Manual

Test Setup
Connector Type
J1 Header, 100 mil, 6 × 2
J2 Header, 100 mil, 5 × 2
J3 Header, 100 mil, 6 × 2
J4 Micro USB
T1 Terminal block, 2 × 1
T2 Terminal block, 2 × 1
T3 Terminal 90A Lug
T4 Terminal block, 2 × 1
T5 Terminal 90A Lug
12 TPS546B24A 2-Phase SWIFT™ Step-Down Converter Evaluation Module
User's Guide

Table 4-5. Connector Functions

Name
N/A
PMBus connector
N/A
Micro USB
PVIN
GND
VOUT
Ext_AVIN
GND
Copyright © 2022 Texas Instruments Incorporated
Description
Do not use
PMBus socket for TI FUSION adaptor
Do not use
Micro USB connector to power EVM from a 5 V USB
source
VIN+ connector
VIN– connector
VOUT+ connector
External AVIN connector
VOUT– connector
