Configuring the Gateway's mso Interface
Username
Logout and Change
Password Buttons
Status icons
Menu bar
Main area
Control Panel
Figure 57. Main Areas on the Web Management Interface
Some menus in the menu bar have submenus associated with them. If you click a menu that
has submenus, the submenus appear below the menu. For example, if you click the
Connection menu, the submenus in Figure 58 appear.
Figure 58. Example of Connection Submenus
