SMC Networks SMCD3GNV User Manual page 48

Option
Gateway Address
Subnet Mask
DHCP Beginning Address
DHCP Ending Address
DHCP Lease Time
SAVE SETTINGS button
RESTORE DEFAULT SETTINGS
FOR IPV4 button
Enable IPv6
Gateway Address
Subnet Mask
DHCP Beginning Address
DHCP Ending Address
DHCP Lease Time
IPv6 Mode
SAVE SETTINGS button
RESTORE DEFAULT SETTINGS
FOR IPV6 button
SMCD3GNV Wireless Cable Modem Gateway User Manual
Configuring the Gateway
Table 7. Local IP Configuration Menu
IPv4
(for computers that use IPv4 Messaging)
IPv4 IP address that the Gateway is to use.
IPv4 subnet mask that the Gateway is to use.
Starting IP address range for the pool of allocated for DHCP IP addresses. The first two fields
match the first two octets in the Gateway's IP address and cannot be changed. The last two
fields let you enter the final two octets in the starting IP address range.
Ending IP address range for the pool of allocated for DHCP IP addresses. The first two fields
match the first two octets in the Gateway's IP address and cannot be changed. The last two
fields let you enter the final two octets in the ending IP address range.
Amount of time a DHCP network user is allowed connection to the Gateway with their current
dynamic IP address. Default is One Week.
After configuring your IPv4 settings, click this button to save them.
Resets the Gateway to the factory default IPv4 settings.
IPv6
(for computers that use IPv6 Messaging)
Check this box to configure the Gateway to use IPv6 settings.
IPv6 IP address that the Gateway is to use.
IPv6 subnet mask that the Gateway is to use.
Starting IP address range for the pool of allocated for DHCP IP addresses. The first two fields
match the first two octets in the Gateway's IP address and cannot be changed. The last two
fields let you enter the final two octets in the starting IP address range.
Ending IP address range for the pool of allocated for DHCP IP addresses. The first two fields
match the first two octets in the Gateway's IP address and cannot be changed. The last two
fields let you enter the final two octets in the ending IP address range.
Amount of time a DHCP network user is allowed connection to the Gateway with their current
dynamic IP address. Default is One Week.
Select the IPv6 mode that the Gateway is to use. Choices are:
link-local only = allows communication among nodes attached to the same link. Packets
•
are not forwarded outside the site. (default)
site-local only = allows communication among nodes within a site or organization.
•
After configuring your IPv6 settings, click this button to save them.
Resets the Gateway to the factory default IPv6 settings.
48
Description
