User Guide
USING THE EVALUATION BOARD
CONTROL PORT
The EVAL-ADAU1860EBZ is configured to serial peripheral inter-
face (SPI) mode by default. To operate the codec in I
asynchronous receiver/transmitter (UART) mode, see
Table 3. Control Port Jumper and Switch (S1) Settings
Communication Port
Address Setting
SPI
Not applicable
2
I
C
S14, default 0x64 (00), 0x65 (01), 0x66 (10),
0x67 (11)
UART
Not applicable
analog.com
2
C or universal
Table
3.
Jumper Settings
Pin 2 to Pin 3 of P1, Pin 2 to Pin 3 of P4, Pin 2 to Pin 3 of P5, and Pin 2
to Pin 3 of P6
Pin 2 to Pin 3 of P1, Pin 2 to Pin 3 of P4, Pin 2 to Pin 3 of P5, and Pin 2
to Pin 3 of P6
Pin 1 to Pin 2 of P1, Pin 1 to Pin 2 of P4, Pin 1 to Pin 2 of P5, and Pin 1
to Pin 2 of P6
EVAL-ADAU1860
Switch Settings
Down
Up
Rev. 0 | 10 of 26
