User Guide
SETTING UP THE EVALUATION BOARD
INSTALLING THE LARK STUDIO SOFTWARE
Download and install the latest version of
the following steps:
1. Download the installer and run the executable file.
2. Follow the prompts, including accepting the license agreement,
to install the software.
Table 1. Default Switch and Jumper Settings
Jumper and Switch Connections
Pin 1 to Pin 2 of P17
Pin 1 to Pin 2 of P48 and JP3 Removed
Pin 1 to Pin 2 of P19 and JP2 Connected
Pin 1 to Pin 2 of P18 and JP1 Connected
Pin 2 to Pin 3 of P26
Pin 2 to Pin 3 of P24
Pin 2 to Pin 3 of P29
S1 Down (SPI), Pin 2 to Pin 3 of P1, Pin 2 to Pin 3 of P4, Pin 2 to Pin 3 of P5, and
Pin 2 to Pin 3 of P6
Pin 1 of S14 to GND and Pin 2 of S14 to GND
Pin 1 to Pin 2 of P8 and Pin 2 to Pin 3 of P27 to P27
Pin 1 to Pin 2 of P104 and Pin 1 to Pin 2 of P105
Pin 1 to Pin 2 of P12 and Pin 1 to Pin 2 of P14
Pin 1 to Pin 2 of P13 and Pin 1 to Pin 2 of P15
analog.com
Lark Studio
by completing
INSTALLING THE USB DRIVERS
If the USB interface is not recognized by the Lark Studio software
and PC, go to the Future Technology Devices International (FTDI)
Chip official web page and download the relevant drivers.
DEFAULT SWITCH AND JUMPER SETTINGS
Table 1
shows the default switch and jumper settings.
Option Selected
AVDD and HPVDD supplied by 1.8 V on-board low dropout (LDO) regulator
IOVDD supplied by 1.8 V on-board LDO
HPVDD_L supplied by 1.3 V on-board LDO
DVDD supplied by 0.9 V on-board LDO
Self boot disabled
REG_EN disabled
ROM boot disabled
SPI communication
2
I
C Address 0x64
The master clock source is the on-board, 24.576 MHz oscillator
ADC0 differential mode
ADC1 differential mode
ADC2 differential mode
EVAL-ADAU1860
