ORDERING INFORMATION

BILL OF MATERIALS

Table 10.
Qty Reference
1 A1
18 BCLK0, BCLK1, FSYNC0, FSYNC1,
SDI0, SDI1, SDO0, SDO1, TP1 to TP9,
and TP20
36 C1 to C18, C48, C52, C57 to C61, C63,
C64, C70 to C75, and C77 to C79
2 C19 and C20
6 C21 to C26
1 C27
6 C28, C29, C31, C34, C36, and C37
5 C30, C32, C35, C38, and C39
3 C33, C40, and C41
1 C42
8 C43, C45, C47, C49 to C51, C53, and
C55
3 C44, C46, and C54
3 C56, C62, and C69
2 C65 and C67
2 C66 and C68
1 C76
2 D1 and D2
3 JP1 to JP3
2 L1 and L2
19 P1, P4 to P6, P8, P12 to P15, P17 to
P19, P24, P26, P27, P29, P48, P104,
and P105
4 P9 to P11 and P30
47 P16, P21, P25, P28, P31 to P43, P45 to
P47, P49 to P58, and P60 to P76
4 P2, P3, P23, and P44
2 P7 and P20
1 P22
1 P59
4 R1, R2, R8, and R9
19 R10 to R19, R26, and R29 to R36
analog.com
Description
Microprocessors supervisory circuit in 4-lead SOT-143, logic
low RESET output
PCB connector, test points, white
0.1 μF ceramic capacitors, 50 V, 10%, X7R, 0603, AEC-Q200
22 pF ceramic capacitors, 50 V, 5%, X7R, 0603
22 μF ceramic capacitors, 16 V, 10%, X5R, 1210
150 pF ceramic capacitors, 50 V, 5%, C0G, 0603, AEC-Q200
1 μF ceramic capacitors, 6.3 V, 10%, X7R, 0402
0.1 μF ceramic capacitors, 6.3 V, 10%, X7R, 0201
10 μF ceramic capacitors, 6.3 V, 20%, X5R, 0402
10 μF ceramic capacitor, 10 V, 20%, X5R, 0603
2.2 μF ceramic capacitors,10 V, 10%, X7R, 0603
0.01 μF ceramic capacitors, 50 V, 10%, X7R, 0603
1 μF ceramic capacitors, 16 V, 10%, X7R, 0603, AEC-Q200,
low equivalent series resistance (ESR)
27 pF ceramic capacitors, 50 V, 5%, C0G, 0603
4.7 μF ceramic capacitors, 16 V, 10%, X6S, 0603
3.3 μF ceramic capacitor, 16 V, 20%, X6S, 0603, low ESR
Diodes, Schottky barrier rectifier
Connector PCB, jumpers,male, two-position
100 nH inductors, surface mount
Connector PCB, 3-position male headers, unshrouded, single
row ST, 2.54 mm pitch, 3.05 mm solder tail
Connector PCB, 3.5 mm surface-mount audio jack stereos
Connector PCB, 2-position male headers, unshrouded, single
row ST, 2.54 mm pitch, 3.05 mm solder tail
Connector PCB, 10-position male headers, unshrouded, double
row ST, 2.54 mm pitch, 3.05 solder tail
Connector PCB, headers, 9-pin, double row
Connector PCB, micro USB 2.0
Connector PCB, header, shrouded ST, 20-position, male
2.4 kΩ resistors, surface-mounted device (SMD), 1%, 1/10 W,
0603, AEC-Q200
0 Ω resistors, SMD, jumper, 1/10 W, 0603, AEC-Q200
EVAL-ADAU1860
Manufacturer Model Number
Analog Devices ADM811TARTZ
Keystone 5002
Electronics
Vishay VJ0603Y104KXAAC
31X
AVX Corporation 06035C220JAT2A
Murata GRM32ER61C226K
E20L
TDK CGA3E2NP01H151
J080AA
Murata GRM155R70J105K
A12D
Yageo CC0201KRX7R5BB
104
Samsung CL05A106MQ5NUN
C
Murata GRM188R61A106M
E69D
Murata GRM188R71A225K
E15D
Murata GRM188R71H103K
A01D
TDK CGA3E1X7R1C105
K080AC
PHYCOMP AC0603JRNPO9BN
(Yageo) 270
Murata GRM188C81C475K
E11D
TDK C1608X6S1C335M0
80AC
Diodes, Inc. DFLS220L-7
Amphenol, FCI 69157-102
Coilcraft 0603CS-R10XGLU
Sullins PBC03SAAN
CUI SJ-3523-SMT-TR
Sullins PBC02SAAN
Sullins PBC05DAAN
Harwin M20-9980445
Hirose ZX62-B-5PA(33)
Omron or 3M XG4C-2031 /
N2520-6003RB
Panasonic ERJ-3EKF2401V
Panasonic ERJ-3GEY0R00V
Rev. 0 | 24 of 26
