2. Specifications

Function Specifications

Table 2.1. Function Specifications
Item
Screen
Assembly type
Screen size
Number of pixels
Display type
Number of colors
Brightness control
Backlight control
Display interface
Input signal
LVDS input
specification
DVI-D input
Cable length which
recommends
Touch panel
Resolution
Detection method
Touch life expectancy
Touch panel interface
Touch panel driver (option)
*1 Using a cable longer than 5 m may reduce the image quality. The cable should be as short as possible as
degradation. The image quality may result even when the cable is 5 m or shorter depending on the type of host
computer or cable.
*2 The touch panel USB interface is only supported on Windows XP/2000/98SE.
*3 It is 262,144 when connecting the LVDS.
FPD-M75VT-DC1, FPD-L75ST-DC1, FPD-H75XT-DC1
FPD-M75VT-DC1
Embedded type
12.1 inches
10.4 inches
640 x 480 dots 800 x 600 dots
TFT Color LCD
262,144 colors 262,144 colors
Adjustment using the back switch or software control from the host
computer
Can be turned on or off by a back switch or via software control from the
host computer.
LVDS input (26 pin half pitch connector)
DVI-D input (24 pin DVI (Female) connector)
26 pin half pitch connector *1
Digital RGB (complies with TMDS) *1
5m or less
4096 x 4096
Resistive-layer analog method
One million repeated touches
(as tested by mechanical touching under 300g of force at a rate of two
presses per second)
Connect to the host computer using either USB *2 or RS-232C.
RS-232C : built-in LVDS/DVI Connector
USB: USB1.1-compliant, TypeB Connector
For Windows : IPC-SLIB-01
Specification
FPD-L75ST-DC1 FPD-H75XT-DC1
15.0 inches
1024 x 768 dots
16,777,216 colors *3
