Contec IPC-DT User Manual

Ipc series 10.4/12.1/15 inch analogue rgb input flat panel display

Advertisement

IPC Series
Analogue RGB input flat panel display
10.4inch
IPC-DT/M20V(PC)T
12.1inch
IPC-DT/L20S(PC)T
15inch
IPC-DT/H20X(PC)T
User's Manual
CONTEC CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPC-DT and is the answer not in the manual?

Questions and answers

Summary of Contents for Contec IPC-DT

  • Page 1 IPC Series Analogue RGB input flat panel display 10.4inch IPC-DT/M20V(PC)T 12.1inch IPC-DT/L20S(PC)T 15inch IPC-DT/H20X(PC)T User's Manual CONTEC CO.,LTD.
  • Page 2: Trademarks

    Copyright 2002 CONTEC CO., LTD. ALL RIGHTS RESERVED No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.
  • Page 3: Table Of Contents

    Table of Contents Copyright ................i Trademarks................ i FCC PART 15 Class A Notice ........i Table of Contents.............. ii 1.Introduction...............1 Features................ 1 Limited One-Year Warranty ........2 How to Obtain Service ..........2 Liability ................ 2 Handling Precautions ..........3 2.Specifications..............7 Function Specifications ............
  • Page 4 6.Power Supply Connection ..........27 Power Supply Connector ..........27 AC Adapter Jack............. 28 AC code removal prevention fitting......29 7.Screen Adjustment and a Setup........31 Menu Screen ..............31 Direct Key ............... 36 Memory of a Setting Value..........36 8.LED Indicators ...............
  • Page 5 User’s Manual...
  • Page 6: Introduction

    1. Introduction 1. Introduction This equipment is an analog RGB signal input, color TFT LCD for use in combination with a host computer such as the CONTEC IPC Series or single-board computer (SBC). Features - Full-bright, wide-angle-of-visibility type of liquid crystals capable of displaying up to 16,777,216 colors(15inch), 262,144 colors(10inch / 12.1inch)
  • Page 7: Limited One-Year Warranty

    Please obtain a Return Merchandise Authorization Number (RMA) from the CONTEC group office where you purchased before returning any product. * No product will be accepted by CONTEC group without the RMA number. Liability The obligation of the warrantor is solely to repair or replace the product.
  • Page 8: Handling Precautions

    - Protect the touch panel against shock to prevent damage. - CONTEC is not liable for a product that has been modified by the user. - For this equipment, use the dedicated power supply unit if possible.
  • Page 9 300g of force at a rate of two presses per second). * CONTEC accepts your request for replacing each consumable in the PANECON-PC as a request for repair (at an additional cost). Contact your local retailer or CONTEC sales office.
  • Page 10 In this case, the touch panel on the screen cannot be used (although display operation is still available.) However, on the following CONTEC panel computers, multiple touch panels can be used together when connected via the USB interface.
  • Page 11 1. Introduction User’s Manual...
  • Page 12: Specifications

    2. Specifications 2. Specifications Function Specifications Table 2.1. Function Specifications < 1 / 2 > Specification Item IPC-DT/M20V(PC)T IPC-DT/L20S(PC)T IPC-DT/H20X(PC)T Screen Assembly type Panel mounted *1 Screen size 10.4 inches 12.1 inches 15 inches Number of pixels 640 x 480 dots...
  • Page 13 2. Specifications Table 2.1. Function Specifications < 2 / 2 > Specification Item IPC-DT/M20V(PC)T IPC-DT/L20S(PC)T IPC-DT/H20X(PC)T Power supply input part Power supply connector 4-pin nylon connector for 12 VDC power supply (Back-mounted, power supply unit [IPC-POA200/12-01] available as an option,...
  • Page 14: General Specifications

    2. Specifications General Specifications Table 2.2. General Specifications Specification Condition IPC-DT/M20V(PC)T IPC-DT/L20S(PC)T IPC-DT/H20X(PC)T Environment Operating temperature 0 - 50ºC (0 - 40ºC when using an IPC-ACAP12-01 (AC switching adapter)) Storage temperature -10 - 60ºC Operating humidity 10 - 90%RH (20 - 80% when using an IPC-ACAP12-01 (AC switching adapter))
  • Page 15: Optical Display Specifications

    2. Specifications Optical Display Specifications Table 2.3. Optical Display Specifications Specifications (25ºC Typ. value) Item Condition IPC-DT/M20V(PC)T IPC-DT/L20S(PC)T IPC-DT/H20X(PC)T φ = 180° 40deg 50deg 45deg Visual angle (vertical) φ = 0° 70deg 70deg 55deg Display in CR≥10 monochrome φ = +90°...
  • Page 16: Outside Dimensions And Part Names

    3. Outside Dimensions and Part Names 3. Outside Dimensions and Part Names Outside Dimensions IPC-DT/M20V(PC)T 4-M4 TAP(Including the mate) (Maximum tapping length:4mm) (18.5) (95.5) 4-M4 TAP (Maximum tapping length:4mm) 4-M4 TAP(Including the mate) (Maximum tapping length:4mm) [mm] Figure 3.1. Outside Dimensions of Main Unit...
  • Page 17: Power Supply Unit

    309.1 157.5 4-M4 TAP (Maximum tapping length:4mm) 4-M4 TAP(Including the mate) (Maximum tapping length:4mm) [mm] Figure 3.3. Outside Dimensions of Main Unit (IPC-DT/H20X(PC)T) IPC-DT/M20V(PC)T with IPC-POA200/12-01 (power supply unit) (1.5) [mm] Figure 3.4. Dimensions of IPC-DT/M20V(PC)T with IPC-POA200/12-01 User’s Manual...
  • Page 18 3. Outside Dimensions and Part Names IPC-DT/L20S(PC)T with IPC-POA200/12-01 (power supply unit) (0.8) [mm] Figure 3.5. Dimensions of IPC-DT/L20S(PC)T with IPC-POA200/12-01 IPC-DT/H20X(PC)T with IPC-POA200/12-01 (power supply unit) [mm] Figure 3.6. Dimensions of IPC-DT/H20X(PC)T with IPC-POA200/12-01 User’s Manual...
  • Page 19: Part Names

    3. Outside Dimensions and Part Names Part Names Front Screen & Touch panel Power LED Screen adjustment switch Right side Back Left side Analog RGB connector USB touch panel connector RS touch panel connector Backlight ON/OFF connector Dip switch Power supply connector AC adapter jack Figure 3.7.
  • Page 20: Analog Rgb Connector

    3. Outside Dimensions and Part Names Analog RGB Connector Table 3.1. Analog RGB Connector Connector type HD-SUB 15pin (FEMALE) Pin No. Signal name Pin No. Signal name N.C. GREEN BLUE N.C. N.C. DDC DATA HSYNC R-GND VSYNC G-GND DDC CLK B-GND RS Touch Panel Connector This connector is RS-232C compliant to be used for touch panel...
  • Page 21: Usb Touch Panel Connector

    3. Outside Dimensions and Part Names USB Touch Panel Connector The USB connector for communication between the host computer and touch panel. Table 3.3. USB Touch Panel Connector Connector type USB Type B (Receptacle) Pin No. Signal name Pin No. Signal name DATA+ DATA-...
  • Page 22: Dip Switch

    3. Outside Dimensions and Part Names Dip Switch A DIP switch is located on the left side of the unit. Switches 1 - 3 are used as the ID setting when connecting multiple touch panels via USB. See Chapter 9 for details on connecting multiple touch panels via USB.
  • Page 23: Backlight On/Off Connector

    3. Outside Dimensions and Part Names Backlight ON/OFF Connector The equipment has a backlight ON/OFF connector on the back. Given below are the pin assignment of the connector and its applicable example. Table 3.6. Remote Control Cable Connector Connector type S2B-XH-A(manufactured by JST) Pin1-2 Function...
  • Page 24: Setting The Display

    4. Setting the Display 4. Setting the Display Installation Requirements To maintain the ambient temperature within the installation environment requirement range, provide a gap of 30mm or more between the main unit and any adjacent equipment. Side view Panel 30mm or more(above) Bottom view 30mm or more(Side) Interface surface...
  • Page 25: Panel Cut

    Cut the display mount panel in the following dimensions. The four corners of the solid-line rectangle define the panel cut dimensions. IPC-DT/M20(PC)T does not need the stud holes because panel can be attached by using the fitting(bundled). For the IPC- DT/L20S(PC)T and IPC-DT/H20X(PC)T, stud holes must be drilled in the panel cut periphery.
  • Page 26 4. Setting the Display [mm] 12- φ 5 Figure 4.5. IPC-DT/H20X(PC)T [15inch] Panel Cut Dimensions and Stud Hole Positions User’s Manual...
  • Page 27: Attaching The Fitting Used To Attach To The Main Unit

    4. Setting the Display Attaching the Fitting Used to Attach to the Main Unit IPC-DT/M20V(PC)T 1. Hold the main unit from the outside of the panel. Figure 4.6. Attaching the Fitting Used to Attach to the Main Unit < 1 / 4 >...
  • Page 28 4. Setting the Display 3. Undo the four screws. (Approximately 10 turns for a 2mm thick panel.) 4. Clip the pawl on the sliding part of the attachment fitting into the hexagonal hole in the main unit. Figure 4.6. Attaching the Fitting Used to Attach to the Main Unit <...
  • Page 29 Stud Spring washer Even washer Panel Packing Display Figure 4.7. Attachment to IPC-DT/L20S(PC)T or IPC-DT/H20X(PC)T Note! The maximum mountable panel thickness is 10 mm for each model. User’s Manual...
  • Page 30: Connection To The Host Computer

    5. Connection to the Host Computer 5. Connection to the Host Computer Purchase individual connection cables as they are not bundled with this equipment. Analog RGB Connection This connection inputs analog RGB display signals to the equipment. Connect the cable to the analog RGB connector on the host computer.
  • Page 31: Touch Panel Data Communications

    - Touch panel driver software is required to use the touch panel. Purchase optional driver software [IPC-SLIB-01 for windows] or download one from the CONTEC’s web site (http://www.contec.co.jp/download/). - The USB touch panel driver software requires V1.20 or later of IPC-SLIB-01.
  • Page 32: Power Supply Connection

    6. Power Supply Connection 6. Power Supply Connection This equipment requires power supply at +12 VDC to operate. For power supply, it has the power connector and the AC adapter jack. Notes! - Connect a power supply to either of the power connector and adapter jack.
  • Page 33: Ac Adapter Jack

    6. Power Supply Connection AC Adapter Jack The AC adapter jack is used to connect the AC adapter [IPC-ACAP12-01] available as an option. Do not connect any AC adapter other than the option. +12V Figure 6.1. AC Adapter Jack User’s Manual...
  • Page 34: Ac Code Removal Prevention Fitting

    6. Power Supply Connection AC code removal prevention fitting (1) When using the AC Adapter 1. Insert the plug of AC Adapter. 2. Tighten the screws on the attachment fitting. Figure 6.2. Code Removal Prevention Fitting (AC Adapter) < 1 / 2 > Figure 6.2.
  • Page 35 6. Power Supply Connection (2) When using the dedicated power supply unit 1. Insert the AC cable. 2. Tighten the screws on the attachment fitting. Figure 6.3. Code Removal Prevention Fitting (Dedicated Power Supply Unit) < 1 / 2 > Figure 6.3.
  • Page 36: Screen Adjustment And A Setup

    7. Screen Adjustment and a Setup 7. Screen Adjustment and a Setup The equipment has screen adjustment switches [MENU], [+], and [-]. Use these switches to adjust the screen. (For the locations of the switches, see “Outside Dimensions and Part Names” in Chapter When using the equipment for the first time or after changing the output screen mode of the host computer, execute AUTO ADJUST first on the menu screen.
  • Page 37 7. Screen Adjustment and a Setup POSITION Even when AUTO ADJUST fails to position the screen correctly, you can adjust the horizontal and vertical positions of the display screen. Select this item to invoke the submenu, select a desired item using [+] or [-], then press [MENU] to accept the setting made.
  • Page 38 7. Screen Adjustment and a Setup SCREEN Select this item to adjust the display status of the screen. Select this item to invoke the submenu, select a desired item using [+] or [-], then press [MENU] to accept the setting made. Figure 7.3.
  • Page 39 7. Screen Adjustment and a Setup WIDTH Select this item to adjust the horizontal display size of the screen. Press [+] or [-] to optimize the item. TOUCHPANEL: Select this item to adjust the status of the touch panel. Select this item to invoke the submenu, select a desired item using [+] or [-], then press [MENU] to accept the setting made.
  • Page 40 7. Screen Adjustment and a Setup BEEP Select this item to turn on or off the click tone of the touch panel. (Factory setting:OFF) ON/OFF setting on the touch panel driver (host side) is also available. See also the driver setting when you change the setting. MAIN MENU: Select this item to return to the main menu.
  • Page 41: Direct Key

    7. Screen Adjustment and a Setup Direct Key BRIGHTNESS : The brightness of the backlight can be adjusted by pressing the [+] and [-] keys without the menu screen displayed. INITIALIZATION: All the settings can be reset to the factory defaults by turning on the equipment while holding down the [MENU] key.
  • Page 42: Led Indicators

    8. LED Indicators 8. LED Indicators The POWER LED on the front face indicates each state of the display as follows: Table 8.1. LED Indicators LED status Description The power supply off or the equipment not started normally Green(ON) Normal operation Green(Flashing) Power save mode Orange(Flashing)
  • Page 43 8. LED Indicators User’s Manual...
  • Page 44: Touch Panel

    Note that the driver software is not bundled with this product. Purchase the one separately or download it from the CONTEC’s web site. For further details, refer to the READ_ME file for each driver. < Option touch panel driver >...
  • Page 45 9. Touch Panel Notes! - The USB touch panel driver software requires V1.20 or later of IPC-SLIB-01. - The USB connection can only be used on Windows XP, 2000, or 98SE. Connect via the RS-232C interface if using a different - Use either USB or RS-232C for connecting the touch panel.
  • Page 46: Usb Multi-Touch Panel

    Touch panel display Figure 9.2. Example of connection of a USB multi-touch panel You can use a CONTEC IPC-PT/600 series panel computer as the host PC. In this case, the ID of the touch panel in the panel computer is fixed at ID7.
  • Page 47 9. Touch Panel User’s Manual...
  • Page 48: Display Mode

    10. Display Mode 10. Display Mode This equipment supports the following display modes: Table 10.1. IPC-DT/M20V(PC)T Number of pixels Dot clock Horizontal frequency Vertical frequency Video mode (dot) (MHz) (kHz) (Hz) 640 x 350 25.18 31.47 *1, *2 640 x 400 25.18...
  • Page 49 - The number of display pixels of the LCD is 640 x 480 dots on the IPC-DT/M20V(PC)T, 800 x 600 dots on the IPC-DT/L20S(PC)T, and 1024 x 768 dots on the IPC-DT/H20X(PC)T. When the input has a resolution lower than the number of display pixels of each model, the screen display is enlarged automatically.
  • Page 50: Options

    - IPC-CV12 : 12.1-inch [IPC-DT/L20S(PC)T] screen protective sheets (10 sheets) - IPC-CV15 : 15-inch [IPC-DT/H20X(PC)T] screen protective sheets (10 sheets) Optional cables - IPC-CBL3-2 : RS-232C cable for touch panels (2m) - IPC-CBL3-5 : RS-232C cable for touch panels (5m) Driver - IPC-SLIB-01 : Driver &...
  • Page 51 11. Options Recommendation Cable (Maker: SANWA SUPPLY INC.) - KC-V2 : RGB display cable(2m) - KC-V5 : RGB display cable (5m) - KU20-2H : USB cable for touch panel (2m) - KU20-5H : USB cable for touch panel (5m) User’s Manual...
  • Page 52 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [03292005] [02072002] Management No. A-46-563 [04182005_rev5] Parts No.
