Design and Integration Files

Schematics, layout files, bill of materials

Equipment Needed

Analog signal source(s) and antialiasing filter(s)
Sample clock source (if not using the on-board crystal oscillator)
Switching power supply (6.0V, 2.5A) for AD9249-65EBZ
Switching power supply (12V, 3,3A) for HSC-ADC-EVALDZ
PC running Windows®
USB 2.0 port
AD9249-65EBZ board
HSC-ADC-EVALDZ FPGA-based data capture kit

Getting Started

This section provides quick start procedures for using the
optional ADC settings are described.
Configuring the Board
Before using the software for testing, configure the evaluation board as follows:
1. Connect the evaluation board to the data capture board, as shown in Figure 1.
2. On the ADC evaluation board, confirm that the jumpers are installed as shown in Figure 2.
3. Connect one 6V, 2.5A switching power supply (such as the CUI, Inc., EPS060250UH-PHP-SZ that is
supplied) to the AD9249-65EBZ.
4. Connect the 12V, 3.3A switching power supply to the
5. Connect the HSC-ADC-EVALDZ
6. On the ADC evaluation board, use a clean signal generator with low phase noise to provide an
input signal to the desired channel(s). Use a shielded, RG-58, 50Ω coaxial cable (optimally 1 m or
shorter) to connect the signal generator. For best results, use a narrow-band, band-pass filter with
50Ω terminations and an appropriate center frequency. (Analog Devices, Inc. uses TTE, Allen
Avionics, and K&L band-pass filters.)

Evaluation Board Hardware

<Coming Soon>
board (P702) to the PC using a USB cable.
Rev 13 Nov 2013 01:51 | Page 3
AD9249-65EBZ board. Both the default and
HSC-ADC-EVALDZ board.
