K-array Pinnacle-KR II Assembly Manual page 9

Pinnacle-KR202 II
Bill of material
4 Kobra-KK102 I Stainless steel meter-long line array element with 2" drivers
1 Thunder-KS2 I Lightweight, multi-tasking 18" self-powered subwoofer
1 Thunder-KS2P I Lightweight, 18" passive subwoofer
2 K-FOOT3 Adapter for standing loudspeakers on top of Thunder sub
4 K-JOINT3 Joining hardware to connect Kobra loudspeakers
1 K-SPKCABLE15 4-pole speaker cable with SpeakON NL4, 15 m (49 ft)
2 K-SPKCABLE2 4-pole speaker cable with SpeakON NL4, 2 m (6.5 ft)
2 K-SPKCABLE235 4-pole joint cable with SpeakON NL4, 22,5 cm (9 in)
1 Power cable with PowerCON TRUE
Pinnacle-KR402 II
Bill of material
4 Python-KP102 I Stainless steel meter-long line array element with 3" drivers
1 Thunder-KS3 I Compact, multi-tasking 21" self-powered subwoofer
1 Thunder-KS3P I Compact, 21" passive subwoofer
2 K-FOOT3 Adapter for standing loudspeakers on top of Thunder sub
4 K-JOINT3 Joining hardware to connect Python loudspeakers
1 K-SPKCABLE15 4-pole speaker cable with SpeakON NL4, 15 m (49 ft)
2 K-SPKCABLE2 4-pole speaker cable with SpeakON NL4, 2 m (6.5 ft)
2 K-SPKCABLE235 4-pole joint cable with SpeakON NL4, 22,5 cm (9 in)
1 Power cable with PowerCON TRUE
Pinnacle-KR
Assembly Manual
3
