Mechanical Drawings - K-array Pinnacle-KR II Assembly Manual

Hide thumbs

Table of Contents

Pinnacle-KR

Assembly Manual

Service

To obtain service:

1. Please have the serial number(s) of the unit(s) available

for reference.

2. Contact the official K-array distributor in your country:

find the Distributors and Dealers list on K-array website.

Please describe the problem clearly and completely to

the Customer Service.

3. You will be contacted back for on-line servicing.

4. If the problem cannot be resolved over the phone,

you may be required to send the unit in for service. In

this instance, you will be provided with an RA (Return

Authorization) number which should be included on all

shipping documents and correspondence regarding

the repair. Shipping charges are the responsibility of the

purchaser.

Any attempt to modify or replace components of the device

will invalidate your warranty. Service must be performed by

an authorized K-array service center.

Cleaning

Use only a soft, dry cloth to clean the housing. Do not use

any solvents, chemicals, or cleaning solutions containing

alcohol, ammonia, or abrasives. Do not use any sprays near

the product or allow liquids to spill into any openings.
