Pinnacle-KR
Assembly Manual
Type
Transducers
Frequency Response
1
Crossover
Max SPL
2
Nominal Impedance
Power Handling
Coverage
Connectors
IP Rating
Dimensions (WxHxD)
Weight
Extensible with dedicated preset according to the midrange crossover point.
1
Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 1 m.
2
Passive loudspeakers requires dedicated preset loaded on board of K-array amplifiers.
New materials and design are introduced into existing products without previous notice.
24
Thunder-KS1P I
12" neodymium magnet
woofer
35 Hz – 150/450 Hz (-6 dB) 35 Hz – 150/450 Hz (-6 dB)
crossover dependent
External DSP-controlled, Low Pass @ 150 Hz up to 450 Hz, preset dependent
134 dB peak
8 Ω
1200 W
peak
Speaker input/parallel output
2x SpeakON NL4
500 x 350 x 440 mm
(19.7 x 13.8 x 17.3 in)
18 kg (39.7 lb)
Thunder-KS2P I
Active subwoofer
18" neodymium magnet 21" neodymium magnet
woofer
30 Hz – 150/450 Hz (-6 dB)
crossover dependent
137 dB peak
8 Ω
1400 W
peak
Omni
Input terminals selectable:
IN+Link 1+/1- (parallel), Link 2+/2-
Link 1+/1- , IN+Link 2+/2- (DEFAULT)
IP54
650 x 500 x 580 mm 735 x 580 x 700 mm
(25.6 x 19.7 x 22.8 in) (28.9 x 22.83 x 20.87 in)
34 kg (75 lb)
Thunder-KS3P I Thunder-KS4P I
2x 18" neodymium magnet
woofer
35 Hz – 150/450 Hz (-6 dB)
crossover dependent crossover dependent
139 dB peak
4 Ω
2800 W
peak
1106 x 500 x 580 mm
(43.5 x 19.7 x 22.8 in)
49,2 kg (108.5 lb)
woofer
141 dB peak
4 Ω
2800 W
peak
53,2 kg (117.3 lb)
