Pinnacle-KR
Assembly Manual
Thank you for choosing this K-array products!
To ensure proper operation, please carefully read the owner's
manuals and safety instruction before using the products.
After reading this manual, be sure to keep it for future reference.
Should you have any questions about your new
device please contact K-array customer service at
support@k-array.com or contact the official K-array distributor
in your country.
Pinnacle-KR is a line of integrated, self-powered
loudspeaker systems composed of Thunder-KS
subwoofers and top line array loudspeaker elements from
the Kobra, Python and Kayman series.
Taking advantage of the modularity of the systems and
thanks to the available accessories for ground stacking or
suspending the loudspeakers, the Pinnacle-KR systems can
be assembled in many configurations suiting any application:
from outdoor light parties to auditorium, from conference
rooms to beach clubs and more.
Enhanced performance and easy tuning are now managed
by the Integrated Electronic Brain – IEB – implemented into
K-array amplifiers. More than a traditional DSP, the built-
in micro electronics driven by the integrated operating
system osKar features extensive sound processing, offering
complete user control over the system performance:
Volumes, Signal Routing, Presets as well as a complete USB
player, are directly manageable from the device via mobile
app and dedicated professional interface.
