Technical Specifications

Type
Transducers
Frequency Response
1
Crossover
Max SPL
2
Coverage
Nominal Impedance
Rated power
Connectors
IP Rating
3
Dimensions (WxHxD)
Weight
With dedicated K-array preset.
1
Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 8 m then scaled at 1 m.
2
More complete water protection with K-IP65KITA and K-IP65KITB accessories (IP65 compliant).
3
Passive loudspeakers requires dedicated preset loaded on board of K-array amplifiers.
New materials and design are introduced into existing products without previous notice.
22
Kobra-KK102 I
16 x 2" neodymium magnet woofers
150 Hz – 18 kHz (-6 dB)
DSP-controlled, High Pass @ 150 Hz
126 dB peak
V. 7° - 35° | H. 120°
8 Ω / 32 Ω selectable
400 W
59 x 1000 x 81 mm
(2.3 x 39.4 x 3.2 in)
2.3 kg (5.07 lb)
Python-KP102 I
Passive line array loudspeaker
12 x 3.15" neodymium magnet woofers
120 Hz – 18 kHz (-6 dB)
DSP-controlled, High Pass @ 120 Hz
134 dB peak
V. 7° - 30° | H. 90°
4 Ω / 16 Ω selectable
720 W
2x SpeakON NL4: 1+/1- transucers/link. 2+/2- through
IP64
89 x 1000 x 118 mm
(3.5 x 39.4 x 4.7 in)
5.8 kg (12.78 lb)
Kayman-KY102
8 x 4" neodymium magnet woofers
150 Hz – 20 kHz (-6 dB)
138 dB peak
V. 7° - 30° | H. 90°
8 Ω / 32 Ω selectable
1200 W
116 x 1000 x 134 mm
(4.6 x 39.4 x 5.3 in)
14.9 kg (32.8 lb)
