K-array Pinnacle-KR II Assembly Manual page 13

E
E
4 mm hex key
Aim the loudspeaker to the audience area and use the top
and bottom hex socket set screws to tightly lock the bracket
configuration.
In order to lock the loudspeaker position tighten
the top and bottom hex socket set screws.
4 mm
hex key
Wall mount (basic bracket)
Lightweight bracket for wall mounting
K-WALL2L
(basic model)
1
m
0 m
1 8
8 i n
7 , 0
2
4 mm hex key
5 mm hex key
Pinnacle-KR
Assembly Manual
3
4
m
0 m
1 8
8 i n
7 , 0
7
