8.1.3

Clamping the tool

By default, the following dimensions must be observed for the
tool:
Measured
variable
Length
of the
clamping
pin, max.
Clamping
bore, ø
The dimensions of the tool may not be greater than those of the
press table. If the tool protrudes beyond the press table, particu-
lar care should be taken.
–
Hand toggle presses Translation of the original operating manual
Setup and accessories
Dimensions (mm)
2.5 2.5 5
HKPE HKPV HKPE
21 25 21
H7 H7 H7
10 10 10
35
5 8/12 8/16
HKPV HKPV HKPV
21 21 29
H7 H7 H7
10 10 15
8
50
HKP
45
H7
25
