Technical Data 5 Hkpe; 5 Hkpv - Gechter HKPE Series Translation Of The Original Operating Manual

5.3.2

Technical data 5 HKPE; 5 HKPV

Dimensions and weights
Standard press
1
–
Hand toggle presses Translation of the original operating manual
Setup and function
1
Force in the
lower part
with permissi-
ble
A 227
A2 243
344
C
D 180
E 90
60
F
G 50
U 21
ø 10H7
V
X 70-195
X 0-40
1
595-715
Y
Weight (kg) 20
Enlarged overhang
2
17
5 HKPV
2 3
max.
14kN
max. 320N
380 234
396 243
360 444
200 180
200 90
120 60
70 50
21 21
ø 10H7 ø 10H7
70-195 115-300
0-40 0-40
610-758 695-815
30 27
Enlarged installation height
3
5
