5.5.7
Sliding tables
Heavy duty mechanical sliding table
Heavy duty mechanical sliding table, with locking pin
The sliding table with locking pin is used to absorb non-vertical
forces.
Separate instructions are available for the sliding tables.
–
Hand toggle presses
Translation of the original operating manual
Setup and function
Sliding table with the spring pressure piece in the press position
Sliding table with locking pin in the loading and removal position
27
5
