Figure 2.8
2.5.4
Wiring Examples
The following illustrate how to connect power to single and dual power supplies.
Figure 2.9
Figure 2.10
RUGGEDCOM RSG2488F
Installation Manual, 07/2021, C79000-G8976-1351-07
M3 Ring Lug
Chassis Ground Connection
Single High AC/DC Power Supply
+
Single Low DC Power Supply
2.5.4 Wiring Examples
+
Installing the Device
17
