3.3

Inserting/Removing the MicroSD Card

The RUGGEDCOM RSG2488F accepts a microSD card for storing configuration files
and/or software updates.
Configuration hazard – risk of data loss
The microSD card must not be removed or replaced during normal operation of the
device. Make sure the device is powered down before removing or inserting the
card.
Mechanical/electrical hazard – risk of damage to the microSD card
•
•
•
Security hazard – risk of unauthorized access and/or exploitation
Make sure to remove the microSD card before decommissioning the device or
sending the device to a third-party.
To insert or remove a microSD card, do the following:
1.
2.
3.
4.
5.
RUGGEDCOM RSG2488F
Installation Manual, 07/2021, C79000-G8976-1351-07
NOTICE
NOTICE
Do not expose the microSD card to extreme temperatures or humidity
Do not expose the microSD card to large magnetic or static electric fields
Do not bend or drop the microSD card
NOTICE
Power down the device.
Unscrew the retention screws and remove the access plate.
2
1
Access Plate
1
MicroSD Card
2
Figure 3.3 Inserting/Removing a MicroSD Card
Without touching the contacts on the card, insert or remove the microSD card.
Install the access plate and finger-tighten the retention screws.
Power up the device.
Device Management
3.3 Inserting/Removing the MicroSD Card
23
