Siemens SIMATIC NET RUGGEDCOM RSG2488F Installation Manual page 36

4.
5.
6.
7.
Installing a Module
To install a line module, do the following:
1.
2.
3.
RUGGEDCOM RSG2488F
Installation Manual, 07/2021, C79000-G8976-1351-07
Pull the module from the chassis to disconnect it.
1
2
Module
1
Chassis
2
Screw
3
Figure 4.2 Removing a Module
Install a new module or a blank module (to prevent the ingress of dust and dirt).
[Optional] If necessary, install the device in the rack.
Connect power to the device.
Make sure power to the device has been disconnected and wait approximately
two minutes for any remaining energy to dissipate.
[Optional] If the device is installed in a rack, remove it from the rack.
Remove the current module from the slot.
4.2 Installing/Removing Line Modules
3
Modules
27
