Alarm Indicator LED
Access Plate
Port Status LEDs
Line Modules
Failsafe Alarm Relay
Power Supply Terminal Block
Chassis Ground Terminal
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RSG2488F:
AC/DC power cord (16 AWG)
Lightning protector
Shielded coaxial cables
Flathead screwdriver
Phillips screwdriver
4 x #6-32 screws
Braided or equivalent ground wire
1.4

Decommissioning and Disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
RUGGEDCOM RSG2488F
Installation Manual, 07/2021, C79000-G8976-1351-07
The alarm indicator LED illuminates when an alarm condition exists.
The removable access plate provides access to the microSD slot.
Use a microSD card to load/store the firmware and configuration
for the device. For information about using a microSD card, refer to
"Inserting/Removing the MicroSD Card (Page
Port status indicator LEDs indicate the operational status of each
port.
State
Solid
Blinking
Off
The device features slots for up to eight line modules. For more
information, refer to
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 12)"
• "Failsafe Alarm Relay Specifications (Page 31)"
A pluggable terminal block. For more information, refer to:
• "Connecting Power (Page 13)"
• "Power Supply Specifications (Page 31)"
Protects the device from power surges and accumulated static
electricity. For information about grounding the device, refer to
"Grounding the Device (Page
Tools/Materials
1.3 Required Tools and Materials
Description
Link detected
Link activity
No link detected
"Modules (Page 25)".
16)".
Purpose
For connecting power to the device.
For protecting the device from harmful electrical
strikes.
For connecting the device to antennas and an
Ethernet network.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For mounting the device to a panel.
For grounding the device to safety Earth.
Introduction
23)".
3
