Power Supplies
•
750 W DC Power Supply
750 W AC Power Supply
Two 750 W AC power supply options, with front-to-back or back-to-front airflow, are provided for the
SLX 9150 Series and SLX 9250 Series switches.
•
750W AC power supply - front-to-back airflow (part no. XN-ACPWR-750W-F)
•
750W AC power supply - back-to-front airflow (part no. XN-ACPWR-750W-R)
Note
AC power input cords are not provided with AC power supplies. You can order an appropriate
cord from Extreme Networks or from your local supplier. The power cord must meet the
requirements listed in
Supplies
For information on installing or replacing an AC power supply, see
Supply
on page 50 .
LEDs on the 750 W DC power supply provide information on the unit's operational status. See
AC Power Supply LEDs
750 W DC Power Supply
Two 750 W DC power supply options, with front-to-back or back-to-front airflow, are provided for the
SLX 9150 Series and SLX 9250 Series switches.
•
750W DC power supply - front-to-back airflow (part no. XN-DCPWR-750W-F)
•
750W DC power supply - back-to-front airflow (part no. XN-DCPWR-750W-R)
For information on installing or replacing a DC power supply, see
Supply
on page 53.
LEDs on the 750 W DC power supply provide information on the unit's operational status. See
AC Power Supply LEDs
on page 19
Power Cord Requirements for AC-Powered Switches and AC Power
on page 80
on page 63 for details.
on page 63 for details.
ExtremeSwitching SLX 9250 Hardware Installation Guide
750 W AC Power Supply
Installing a 750 W Internal AC Power
Installing a 750 W Internal DC Power
750 W
750 W
19
