About this Document
Each SLX 9250 Switch has a management port, a console port, a USB port, and SLX 9250 Advanced
Feature License. A four-post mounting kit (part no. XN-4P-RKMT298) is provided with each switch. The
following table lists the specific interfaces for each switch.
Table 4: SLX 9250 Switch Models
Part number
SLX9250-32C (SLX 9250-32C
base)
SLX9250-32C-AC-F (SLX
9250-32C with front-to-back
airflow)
SLX9250-32C-AC-R (SLX
9250-32C with back-to-front
airflow)
Table 5: Supported SLX 9250 Switch Power Supplies
Part number
XN-ACPWR-750W-F
XN-ACPWR-750W-R
XN-DCPWR-750W-F
XN-DCPWR-750W-R
The following table list the supported SLX 9250 Switch Fan assemblies.
Table 6: Supported SLX 9250 Switch Fan Assemblies
Part number
XN-FAN-001-F
XN-FAN-001-R
Description
32 QSFP+/QSFP28 100GbE/ 40GbE ports,
128 x 25/10 GbE using break-out cables, 8
Core Processor, 16GB DDR4 ECC memory,
128GB SSD memory, 2 unpopulated power
supply slots, 6 unpopulated fan slots.
32 QSFP+/QSFP28 100GbE/ 40GbE ports,
128 x 25/10 GbE using break-out cables, 8
Core Processor, 16GB DDR4 ECC memory,
128GB SSD memory, dual power supplies, 6
fan units, front-to-back airflow.
32 QSFP+/QSFP28 100GbE/ 40GbE ports,
128 x 25/10 GbE using break-out cables, 8
Core Processor, 16GB DDR4 ECC memory,
128GB SSD memory,, dual power supplies, 6
fan units, back-to-front airflow.
Description
Modular 750W AC power supply, Front-to-Back
airflow
Modular 750W AC power supply, Back-to-Front
airflow
Modular 750W DC power supply, Front-to-Back
airflow
Modular 750W DC power supply, Back-to-Front
airflow
Description
Fan unit, Front-to-Back airflow
Fan unit, Back-to-Front airflow
ExtremeSwitching SLX 9250 Hardware Installation Guide
Supported hardware and software
Introduced OS Currently
supported
SLX-OS 20.1.1 Yes
SLX-OS 20.1.1 Yes
SLX-OS 20.1.1 Yes
Introduced OS Currently
supported
SLX-OS 20.1.1 Yes
SLX-OS 20.1.1 Yes
SLX-OS 20.1.1 Yes
SLX-OS 20.1.1 Yes
Introduced OS Currently
supported
SLX-OS 20.1.1 Yes
SLX-OS 20.1.1 Yes
