General

4 General
4.1

Authorized use

The device (FTZ-MULTI-15-D without grippers) is specially designed for transportation and handling of:
●
single stone elements or of layers of stones (e.g. kerbstones etc.) by mounting the grippers
WB-G-120 (4310.0943);
●
single stone elements (e.g. kerbstones) by mounting the grippers WB-G-42 (4310.0942);
●
roughly-cut ashlar rocks by mounting the grippers WB-SQ (4310.0941);
●
customary prefabricated concrete products, with clean gripping surface; like steps, kerbs (also natural
kerbs), as well as "Kassler Bord" (Bus- and Train-profil-stones) and also "coping stones".
This device can be used at any lifting device/support frame (like excavator or crane).
Only stone elements with parallel and plane surface are allowed to be picked-up and handled.
Because the gripping good could fall down.
The device is series equipped with:
●
universal adjustable gripping range.
●
suspension bolt for lifting tackle (crane-hook, belt etc.) at support frame/lifting device
●
Automatic release fort he fully automatic switch over from „full" to „empty".
ACCESSORIES:
●
Adapter A-FTZ-KB (Order-Nr.: 43100575) for „Kasseler-Kerb Stone" to extend gripping depth on one
side to 290 mm.
●
Height adjustment HVA-FTZ-D (43101348)
ATTENTION: The use of this device is only permitted in proximity to the ground.
