CHT - Ceiling Hinge Telescopic
Before you start, check the following:
-The product is in good condition
-No damage to any parts
-Wiring is all secure
-The unit is in the closed position
-Test the mechanism by running it up and down, best done with it upside down on the floor
-See page 13-16 for controls.
Loosen hex bolts to
remove Main Tray
Control box setup
- THE BOX MUST BE EASY TO ACCESS!
- Connect the control box to the DC power supply and the
PSU to the mains
- Connect the infrared remote sensor even if you are going
to use switch control
- See operations page
Page 5 of 18 // email info@futureautomation.co.uk tel: +44 (0) 1438 833577 fax: +44 (0) 1438 833565
You must remove the Main Tray
by loosening the 2 or 4 hex
head bolts and lift off before you
can disassemble the Box.
