FSE90 Flat Screen Electric Wall Mount
Screen fitment
Before you start, check the following:
-The product is in good condition
-No damage to any parts
-Wiring is all secure
-The unit is in the closed position
Screen symmetrical
about this centre line
If your screen is not a VESA compatible, then a custom adapter will need to be added to the FSE90
bracket to suit your screen. Further instructions relating to any custom mount will be included with
the custom adapter.
When fitting the screen to the mechanism, make sure that the centre of any adaptor plate is in line
with the centre hole on the mechanism.
Page 5 of 16 // email info@futureautomation.co.uk tel: +44 (0) 1438 833577 fax: +44 (0) 1438 833565
