Terminal

Function/Description

Legend

Connect 120VAC 60Hz to these terminals: L to hot, N to neutral.

L, N

Do not use terminal marked [G] (Fig. 1a, pg. 5).

+ DC –

Refer to MaxFitFE Series Configuration Chart, pg. 2 (Fig. 1h, pg. 5).

Trigger EOL

Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,

Supervised

normally closed from an FACP output circuit (power-limited input) (Fig. 1d, pg. 5).

NO, GND RESET FACP interface latching or non-latching (power-limited) (Fig. 1e, pg. 5).

+ AUX –

Auxiliary Power-Limited output rated @ 1A (unswitched) (Fig. 1f, pg. 5).

Indicates loss of AC power, e.g. connect to audible device or alarm panel.

AC FAIL

Relay normally energized when AC power is present.

NC, C, NO

Contact rating 1A @ 30VDC (power-limited) (Fig. 1b, pg. 5).

Indicates low battery condition, e.g. connect to alarm panel.

BAT FAIL

Relay normally energized when DC power is present. Contact rating 1A @ 30VDC.

NC, C, NO

A removed battery is reported within 5 minutes.

Battery reconnection is reported within 1 minute (power-limited) (Fig. 1b, pg. 5).

Stand-by battery connections.

+ BAT –

Maximum charge current 1.54A (non power-limited) (Fig. 1g, pg. 5).

Power Supply Board Stand-by Battery Specifications

eFlow4NB:

Battery

7AH

12AH

40AH

65AH

eFlow6NB:

Battery

7AH

12AH

40AH

65AH

eFlow102NB:

Battery

7AH

12AH

40AH

65AH

eFlow104NB:

Battery

7AH

12AH

40AH

65AH

*Only these configurations can be utilized in ULC-S319 installations.

MaxiFit11FE/13FE/33FE/35FE/37FE/55FE/75FE/77FE Expandable Power Systems Installation Guide
