Terminal Identification:
Power Supply Board
Terminal Legend
Function/Description
L, G, N
Connect 115VAC to these terminals: L to Hot, N to Neutral.
– DC +
12VDC @ 10 amp continuous outputs.
*AC FAIL
Indicates loss of AC power, e.g. connect to audible device or alarm panel. Relay normally energized
when AC power is present. Contact rating 1 amp @ 120VAC / 28VDC
NC, C, NO
*Low Battery NC,
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized when DC
power is present. Contact rating 1 amp @ 120VAC / 28VDC Low battery threshold: 12VDC output
C, NO
threshold set @ approximately 10.5VDC
– BAT +
Stand-by battery connections. Maximum charge rate 0.7 amp.
*Note: Supervised Models Only.
PD4/PD4CB/PD8/PD8CB/PD16W/PD16WCB - Power Distribution Module
Terminal Legend
PD4/PD4CB PD8/PD8CB
1P to 4P
1P to 8P
SMP1012Xseries
All manuals and user guides at all-guides.com
PD16W/PD16WCB
1P to16P
Positive DC power outputs.
Function/ Description
- 5 -
