Power Supply Board Terminal Identification:

Terminal Legend
L, G, N
+ DC –
Trigger EOL
Supervised
NO, GND
RESET
+ AUX –
AC FAIL
NC, C, NO
BAT FAIL
NC, C, NO
+ BAT –

Access Power Controller Terminal Identification:

Terminal Legend
– Power +
– Control +
TRIGGER INPUT 1-
INPUT 8 IN, GND
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT –
FACP INTERFACE
NC, C, NO
- 8 -
Function/Description
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral.
Do not use terminal marked [G].
Factory connected to ACM8 board.
Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,
normally closed from an FACP output circuit (Class 2 power-limited input) (Fig. 3, pg. 10).
FACP interface latching or non-latching (Class 2 power-limited) (Fig. 3, pg. 10).
Auxiliary Class 2 power-limited output rated @ 1A (unswitched) (Fig. 3, pg. 10).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
Relay normally energized when AC power is present.
Contact rating 1A @ 30VDC (Class 2 power-limited) (Fig. 3, pg. 10).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1A @ 30VDC.
A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (Class 2 power-limited) (Fig. 3, pg. 10).
Stand-by battery connections.
Maximum charge current 1.54A (non power-limited) (Fig. 3, pg. 10).
Function/Description
12VDC or 24VDC from power supply/charger (factory connected).
These terminals are paralleled to the [– Control +] terminals.
These terminals are paralleled to the [– Power +] terminals. These terminals can be
connected to an external Listed power-limited access control power supply to provide
isolated operating power for the devices (Not evaluated by UL).
Jumpers J1 and J2 must be removed.
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir's, etc.)
12VDC to 24VDC trigger controlled outputs. Maximum load per output is 2.5A.
Maximal11F: P/S 1 - 10.1-13.2VDC @ 3.3A P/S 2 - 10.1-13.2VDC @ 3.3A or
P/S 1 - 20.28-26.4VDC @ 3.6A P/S 2 - 20.28-26.4VDC @ 3.6A or
P/S 1 - 10.1-13.2VDC @ 3.3A and P/S 2 - 20.28-26.4VDC @ 3.6A.
Maximal33F: P/S 1 - 10.0-13.2VDC @ 5.3A P/S 2 - 10.0-13.2VDC @ 5.3A or
P/S 1 - 20.28-26.4VDC @ 5.6A P/S 2 - 20.28-26.4VDC @ 5.6A or
P/S 1 - 10.0-13.2VDC @ 5.3A and P/S 2 - 20.28-26.4VDC @ 5.6A.
Maximal55F: P/S 1 - 10.03-13.2VDC @ 9.3A and P/S 2 - 10.03-13.2VDC @ 9.3A.
Maximal75F: P/S 1 - 10.03-13.2VDC @ 9.3A and P/S 2 - 20.17-26.4VDC @ 9.6A.
Maximal77F: P/S 1 - 20.17-26.4VDC @ 9.6A and P/S 2 - 20.17-26.4VDC @ 9.6A.
Fail-Safe [NC positive (+) & COM Negative (–)], Fail-Secure [NO positive (+) & COM Negative
(–)], Auxiliary output [C positive (+) & COM Negative (–)] (When using AC power supplies
polarity needs not to be observed), NC, C, NO convert to dry form "C" 5A 24VAC/VDC rated
dry outputs when fuses are removed. Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 5-9, pg. 12).
Form "C" relay contact rated @ 1A 28VDC for alarm reporting (not evaluated by UL).
