Altronix eFlow3N Installation Manual page 9

Fig. 6 - eFlow3NX Configuration
Green
Lead
120VAC power mains
non power-limited
Optional Rechargeable Stand-by Battery
Note: 12V batteries required for
CAUTION: When power supply board is set for 12VDC use only one (1) 12VDC stand-by battery.
Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing.
12AH Rechargeable batteries are the largest batteries that can fit in this enclosure.
A UL listed external battery enclosure must be used if using 40AH or 65AH batteries.
eFlow3N Series Installation Guide
L G N
1P 1N 2P 2N
DC Output to Devices (power-limited)
(refer to Fig. 3a or 3b for board configuration, pg. 6)
for UL294 Applications
ULC-S319 installations.
Switch Detail
Switch On - 12V
Switch Off - 24V
AC1
NC C NO NC C NO
AC FAIL BAT FAIL
Battery & AC
Supervision Circuit
(power-limited)
PD4UL/
PD4ULCB
3P 3N 4P 4N
Optional Rechargeable Stand-by Battery
Enclosure
Edge of
Enclosure
Tamper Switch
(included)
To Access Control Panel or
UL Listed Reporting Device
OFF - 24V
ON - 12V
AC DC
TRIGGER EOL NO GND
+AUX-
SUPERVISED RESET
power-limited
P N
for UL294 Applications
Note: 12V batteries required for
ULC-S319 installations.
- 9 -
