Altronix eFlow3N Installation Manual page 6

Fig. 2 - Battery Trouble Indication
For Canadian use, a red indicating lamp must be visible from the exterior of this enclosure.
Wire one leg of a UL Listed, power-limited power source to the indicating lamp.
Wire the second leg of the power source to the indicating lamp in series with the battery fail relay contact
terminals marked [BAT FAIL - C, NO] (Fig. 2, pg. 6).
AC FAIL
POWER
NC C NO
SOURCE
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Fig. 3a - PD4UL Power Distribution Board
Replace fuses with the same type and rating 3.5A/250V
F1 F2
1P 1N 2P 2N
DC Output to devices
1P-4P Power Outputs,
1N-4N Common Outputs
Fig. 3b - PD4ULCB - Power Distribution Board
F1 F2
1P 1N 2P 2N
DC Output to devices
1P-4P Power Outputs,
1N-4N Common Outputs
- 6 -
BAT FAIL
NC C NO
Power Distribution Module(s):
F3
3P 3N 4P 4N
From Power Supply
(Factory Installed)
F3 F4
3P 3N 4P 4N
From Power Supply
(Factory Installed)
RED INDICATING
LAMP
F4
LED
Board
LED
Board
eFlow3N Series Installation Guide
