Altronix eFlow3N Installation Manual page 11

Enclosure Dimensions (BC300):
eFlow3N, eFlow3N4, eFlow3N4D
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm)
1.20"
(30.5mm)
1.40"
(35.6mm)
3.25" (82.6mm)
1.0" (25.4mm)
eFlow3N Series Installation Guide
1.40"
4.85" (123.2mm)
(35.6mm)
0.75"
(19.1mm)
1.0"
(25.4mm)
4.85" (123.2mm)
12.5" (317.5mm)
11.0" (279.4mm)
10.5" (266.7mm)
1.40"
(35.6mm)
1.20"
(30.5mm)
0.75"
(19.1mm)
0.9375" (23.8mm)
0.9375" (23.8mm)
3.25" (82.6mm)
1.0"
(25.4mm)
1.20"
(30.5mm)
1.40"
(35.6mm)
