Display Panes
The BWConfig display is divided into 4 panes.
X-gateway Configuration
Modbus Configuration
J1939 Configuration
J1939 I/O Configuration
Tool Operations
The following operations are available through the BWConfig menus and tool bar.
Open File
Save File
Refresh Device Status
Upload Configuration
Download Configuration
© 2012 HMS Industrial Networks AB
Module type and status information about the
X-gateway module that was detected.
Configuration of Modbus network parameters
and status of the network interface.
Configuration of J1939 network parameters
and status of the network interface.
Configuration of the content and layout of the
I/O tables.
Open a previously saved X-gateway configu-
ration.
Save the current X-gateway configuration to a
file.
Refresh the module identity and status infor-
mation. This will update the current status
information shown by the tool. This can also
be used to start the detection process if a mod-
ule has not been detected by the tool, or the
connection has been changed to a different
module.
Read the configuration that is currently stored
in the X-gateway module. This will overwrite
any configuration that is displayed on the
tool's user interface.
Send the configuration shown on the tool's
user interface to the X-gateway module.
Configuration 3-4
Doc.Id. HMSI-168-25
