J1939 Baud Rate

The X-gateway is capable of supporting communication baud rates on the J1939
network of 250K and 500K baud. The correct baud rate must be configured
through the BWConfig Baud Rate option in the J1939 Configuration pane.
© 2012 HMS Industrial Networks AB
Important: The standard baud rate for J1939 is 250K baud. Do not
set the baud rate to 500K baud unless you are certain that all devices
on the network are communicating at 500K baud.
Important: Configuring the module with the incorrect baud rate may
cause other devices on the network to experience bus-off faults.
