Log Files
System Error Log
System Info Log
ControlLogix Log
View All Logs
Administration Menu
Browse File System
AN-X maintains various logs to record diagnostic and error messages.
Use the Log Files menu in the web interface to view these logs.
The System Error log records errors that occur during AN-X operation.
This log is normally empty.
The System Info Log records informational messages during startup and
normal operation.
The Ethernet/IP log shows messages and errors associated with the
ControlLogix scheduled data operation.
Use View All Logs to list and view all the AN-X logs. To view a log file,
double click on the file name.
The Administration Menu is used to set the AN-X IP address and to view
and edit files on AN-X. The file edit function is password protected and
is used only for AN-X technical support.
If you are required by technical support to examine files on the AN-X,
select Administration/Browse File System.
