63
AN-X-MOD (Master) Page
The contents of the right pane depend on the current command being
executed.
S908 I/O Network
Select Automation Network/S908 I/O Network Configuration to
configure the I/O the AN-X-MOD (Master) is to scan.
Autoconfiguration
If you are autoconfiguring the S908 remote I/O network, make sure the
network is connected to the AN-X-MOD (Master).
To configure just the I/O, check Auto-configure S908 network.
To configure the remote I/O network and also generate a default
ControlLogix configuration on the AN-X, check Auto-configure S908
network and ControlLogix configuration
Click the Auto-configure Network button.
