Quick Start - ProSoft Technology AN-X-MOD User Manual

6
Page AN-X-MOD (Master)
Step
1 Install the AN-X Windows software
2 Power up the AN-X, connect it to Ethernet and use
AnxInit to assign it an IP address
3 Connect AN-X to the Modicon S908 network
4 Use the AN-X web interface to autoconfigure the
Modicon network and ControlLogix configuration
5 Configure the AN-X in RSLogix 5000
6 Scan I/O, read inputs and write outputs
7 Use the web interface to create alias tags for
RSLogix 5000
8 Import the tags into RSLogix 5000
9 Use the tags to access data
November 2011

Quick Start

See page
5
7
4
18
31
36
37
