1. Connect both AN-X modules to the S908 network.
2. Autoconfigure the primary AN-X module. Create both remote I/O
and ControlLogix configuration files.
3. Upload the ControlLogix configuration to the computer and edit it.
4. Uncomment the RedundEna line and add a prefix that uniquely
identifies the AN-X.
Map RedundCtl to connection 0. The autoconfiguration maps it
•
to outputs to the connection to slot 0 but comments it out.
Map RedundSts to the inputs for any connection. The
•
autoconfiguration maps it to outputs to the connection to slot 15
but comments it out.
Set the ClxPrefix.
•
For each connection, add names to the DataInput and
•
DataOutput parameters. These names should match the names
of the internal ControlLogix arrays that will hold the data.
Include the LongInput option if the configuration contains 800
•
series modules
5. Save the modified file and upload it to the primary AN-X.
6. Autoconfigure the secondary (backup) AN-X module. Create both
remote I/O and ControlLogix configuration files.
7. Upload the ControlLogix configuration to the computer and edit it.
Uncomment the RedundEna line and add a prefix that uniquely
•
identifies the AN-X.
Map RedundCtl to connection 0. The autoconfiguration maps it
•
to outputs to the connection to slot 0 but comments it out.
Map RedundSts to the inputs for any connection. The
•
autoconfiguration maps it to outputs to the connection to slot 15
but comments it out.
Set the ClxPrefix. It should match the ClxPrefix for the primary
•
AN-X.
For each connection, add names to the DataInput and
•
DataOutput parameters. These names should match the names
of the internal ControlLogix arrays that will hold the data and
should match the names in the primary AN-X
Include the LongInput option if the configuration contains 800
•
series modules
8. Save the modified file and upload it to the secondary (backup)
AN-X.
