Example:
Slot=6,Type=ACO_020_00
CfgLen=6,0x8001,0x5555,0x0000,0x0000,0x0000,0x0000
The leading 0x indicates a hexadecimal number.
Some Quantum discrete output modules, for example, the DRA 840 00,
can be configured to either set their outputs either to the last value or to a
user defined value when they lose communication with the network
master. To set these modules to hold their last state, add a line after the
slot definition that contains the keyword CfgOutLast.
Example:
Slot=4,Type=DRA_840_00
CfgOutLast
If you use both CfgOutLast and additional numerical parameters, they
can be on the same line or on separate lines. CfgOutLast should be first.
If you do not enter any parameter data, AN-X uses the default parameters
from its module database.
Refer to the document AN-X-MOD-Parameters supplied with the AN-X
for detailed information about parameters for specific Quantum modules.
Sample RIO Configuration File
In this example, drop 1 is an 800 series drop and drop 2 is a Quantum
drop.
Drop=1
Rack=1
Slot=4, Type=B804
Slot=5, Type=B805
Rack=2
Slot=4, Type=B888
EndDrop
Drop=2
Rack=1
Slot=4,Type= DAI_353_00
Slot=7,Type= DAO_840_00
