EZ VMS Lite
4.1.3 Save / Save As
If you are working with an already previously saved file, when you click on the 'Save'
option the changes are saved in the same file. If you are working with an unsaved file
loaded from a EZ VMS Lite, the following screen appears to prompt you to "Save As".
Choose a new file name to save as or overwrite an existing file.
4.1.4 Export
To export a binary file from the RPI to the Unit to configure it, click on the 'Export' menu
option and a dialog box appears prompting you to choose a binary file for export.
If you want to export the file you have just collected from the Unit, you have to save and
close the file and then export. If you try to export the file that is currently open, the RPI
prompts you to save and close the file first and then export the desired file.
4.1.5 Detect IP Settings
Use this option to find the IP address of the built-in Ethernet port of the EZ VMS Lite or if
an external Serial to Ethernet converter is being used.
Keep the unit powered off, select the "Detect IP address" option and then switch on the
power to the unit.
The IP address is broadcast by the unit on power up and this will be captured and
displayed in the window as shown above. Use these details to communicate with the EZ
VMS Lite using the Ethernet mode.
