It is very important that the System parameters be programmed correctly for the EZ
VMS Lite to function properly. These parameters are protected by a password to ensure
that only the installer has the permission to access these parameters.
The EZ VMS Lite should be configured to work correctly with the PBX to which it is
connected, as a lot of parameters are very PBX-specific. Some global parameters (Usage
Parameters) are also set through 'System Parameters'.
After you press 5 for 'System Parameters', the EZ VMS Lite prompts you with the
following choices:

Press 1 for PBX Parameters. (1.5.1)

Press 2 for Usage Parameters. (1.5.2)

Press 6 to Listen to Serial Number. (1.5.3)
1.5.1 PBX Parameters
Some system parameters require a special programming method, as some special
characters are required to be entered.
For example, while programming the 'Enable String', 'Disable String' for Message
Waiting Lamp, In-band Strings, Transfer & Retrieve Strings, you have to enter a Pause or
a Hook-flash etc. as part of the desired string to be used by the EZ VMS Lite.
For all such special entries, the following two-digit combination must be used while
programming :
**
*0
*1
*2
*3
*4
*5
*6
*7
*8
When you select the "PBX Parameters" programming menu, the unit prompts you with:

Press 1 to Edit Hook-flash Timing (1.5.1.1)

Press 2 to Edit Off-hook To Message Delay (1.5.1.2)

Press 3 to Edit Delay after Hook-flash (1.5.1.3)

Press 4 to Select Dialing Mode (1.5.1.4)

Press 5 for Message Waiting Lamp Parameters (1.5.1.5)

Press 6 for In-band String (1.5.1.6)

Press 7 for Transfer & Retrieve Strings (1.5.1.7)

Press 8 for Cadence Values (1.5.1.8)
1.5.1.1 Hook-flash Timing:
= *
= Hook-flash
= Pause
= #
= Extension place holder
= Ignore character
= A
= B
= C
= D
