Power Supply/Charger
Red (DC)
ON
ON
OFF
OFF
Power Distribution Module
Green (AC)
ON
OFF
Power Supply/Charger
Terminal Legend
L, N
– DC +
Trigger EOL
Supervised
NO, GND RESET
+ AUX –
AC Fail
NC, C, NO
Bat Fail
NC, C, NO
– BAT +
Power Distribution Module
Terminal Legend
PD8UL/PD8ULCB
1P to 8P
1N to 8N
eFlow6N Series Installation Guide

LED Diagnostics:

Green (AC/AC1)
ON
OFF
ON
OFF
Power Distribution Module Status
Normal operating condition.
No Power Output.

Terminal Identification:

Function/Description
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral (non power-limited)
(Fig. 1a, pg. 6).
12VDC or 24VDC nominal @ 6A continuous output (power-limited output) (Fig. 1h, pg. 6).
Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,
normally closed from an FACP output circuit (power-limited input) (Fig. 1d, pg. 6).
FACP interface latching or non-latching (power-limited) (Fig. 1e, pg. 6).
Auxiliary Class 2 power-limited output rated @ 1A (unswitched) (Fig. 1f, pg. 6).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
Relay normally energized when AC power is present.
Contact rating 1A @ 30VDC (power-limited) (Fig. 1b, pg. 6).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1A @ 30VDC.
A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (power-limited) (Fig. 1b, pg. 6).
Stand-by battery connections. Maximum charge current 1.54A (non power-limited)
(Fig. 1g, pg. 6).
Terminal Legend
PD16W/PD16WCB
1P to 16P
1N to 16N
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
Function/Description
Positive DC power outputs.
Negative DC power outputs.
