Features

ITR-02 Juno Tower Receiver

Front
1
2
3
1
Integrated Sensor
Integrated high sensitivity infrared diode array
covers a typical classroom without the need for
additional sensors.
2
2.1 Speaker Array
Two mid-range/HF drivers and one woofer provide
full, rich stereo sound. The array design ensures
good room coverage even with just one Tower.
3
LCD Touchscreen
Full-color touch screen puts daily system
controls in one easy-to-find place.
4
Stereo Quick Connect
Easily and quickly connect an MP3 player or
other audio device.
5
Table/shelf/desk Stand
Sturdy desk stand is easily removed for wall mounting.
6
Additional Sensor Ports
Two ports for adding sensors for use in large or
odd shaped rooms.
7
Channel Expansion Module Bay
Add the optional Channel Expansion Module to
use up to five microphones with the Juno Tower.
8
Wall Mount Screw Taps
100mm VESA mount compliant.
6
7
8
9
10
11
12
14
4
5
(behind main cover)
6
Back
9
Transmitter/USB Cable Hook
Neatly hang your transmitters while charging
from the tower. When not charging, the USB cable
hangs from the center of the hook.
10
Bluetooth Audio Receiver
®
Easily pair with phones, tablets, and computers to
play audio wirelessly from anywhere in the room.
OR
Speaker Expansion Module Bay
Install the optional module to add additional
speakers (up to six) for expanded audio coverage.
11 Juno
Connect Module Bay
Optional module for adding software and voice
control of AV devices plus, in conjunction with
Conductor, two-way communication between
classroom and front office.
12
Page Override Module Bay
Simply install the optional module to mute all
audio whenever an announcement is made over
the school's public address system.
13
Power Jack
14
Power Switch
13
