ITM-02 Pendant Microphone
1 Amazing Sound Quality
With FrontRow's ClearVoice
synthesis technology, the ITM-02 uses a
single cardioid microphone element to
deliver superb pickup and audio quality.
And combined with a high-isolation, low-
noise, open air microphone suspension,
the ITM-02 minimizes noise from friction
against clothing, buttons or jewelry.
2 Mute Indicator
OFF/STANDBY . . . . . . . . . . . . . . . Un-muted
SOLID RED . . . . . . . . . . . . . . . . . . . . . . Muted
3 Power Indicator
SOLID GREEN . . . . . . . . . . . . . . . . Power On
OFF . . . . . . . . . . . . . . . . . . . . . . . . . . Standby
4 One-Touch Button
Controls all of the features of the Pendant
Microphone. Use with voice command to
activate the Juno lesson capture software
and control your Juno Tower.
When the Pendant Microphone is in
standby mode:
PRESS MOMENTARILY . . . . . . . . . . Awaken
When the Pendant Microphone is active:
PRESS MOMENTARILY . . . .Mute / Un-mute
PRESS AND HOLD . . . .Issue Voice Command
5 Superior Comfort
Lightweight (just 73.7g/2.6oz) with soft
backing that provides comfort and reduces
friction noise from contact with clothing,
buttons or jewelry.
6 Battery Indicator
In Use
OFF . . . . . . . . . . . . . . . . . . . Battery Charged
FLASHING RED . . . . . . . . . . . . . Battery Low
When Charging
SOLID RED . . . . . . . . . . . . . . . . . . . .Charging
SOLID GREEN . . . . . . . . . . . . Fully Charged
FLASHING RED/GREEN. . . . . . Charge fault
7 Lithium Ion Battery
3-year life expectancy, lightweight,
rechargeable lithium ion battery.
™
digital
8
1
2
3
4
10
8
8 Charging / Programming Jack
For charging via USB cable or for
configuring settings using the FrontRow
Microphone Settings application.
9 Portable Audio Interface
3.5mm audio input jack lets you use the
Pendant Microphone to transmit audio
from any secondary audio source such as
a computer or MP3 player.
10 Charge Contacts
For use with the optional IMC-01
microphone charger.
11 Adjustable power
Adjust the power to increase either
battery life or range.
12 Programmable channels
Program the switch positions to 2 of 5
available channels.
13 Custom naming
Assign custom names to microphones for
easy identification on the Tower LCD or in
the optional FrontRow Desktop or Teacher
Edition software.
Front
Bottom
10
9
5
6
7
